Details

CHEVROLET VOLT OEM Integrated Backup Camera

The FC-CML-VOL systems package is a comprehensive high definition Rear View Camera and Factory Connect Harness for your CHEVROLET. The OEM style Rear View Camera is mounted above the license plate area and connects to the Factory specific CHEVROLET Harness behind the existing screen. Once the vehicle is placed into reverse the high resolution image of the backup camera will automatically appear on the factory display for safe navigation. This kit is a simple OEM integration package that maintains your factory set up while upgrading your vehicle with a Rear View Camera System.

CHEVROLET VOLT Systems COMPATIBILITY

CHEVROLET Model	Model Year	Multimedia System
VOLT	2013-2016	with MyLink

CHEVROLET VOLT Factory Connect Harness FEATURES

Features

Factory CHEVROLET Connect Harness
Plug & Play configuration
Quick Connect to Video Cable and Rear Camera
Automatic Reverse trigger activation
Rear Camera Input (RCA)
Parking Guide Line Option (ON/OFF)

CHEVROLET VOLT Backup Camera FEATURES

Features

Style Backup Camera fitment
SONY CCD HD
Vivid Color High Resolution
170° Wide Angle View
Parking Guide Lines (can be turned on/off)
Waterproof Ip68
Shockproof
Simple Installation

Specifications

Specification Terms	Product Values
Image Sensor	CCD HD Sony
Power Supply	DC12V±1V
Power	<1W
Effective Pixels	728*582
Resolution (TV Line)	520
Electronic Shutter	1/60, 1/10,000 sec
Lens Angle	170°
Min. Illumination	0.01lux
IP Rating	Ip68
S/N Ratio	≥48dB
Video Output	1.0vp-p.75Ω
Current Consumption	30-60mA
Operating Temp. (F)	-20~+100
Storage Temp. (F)	-40~+120
TV System	NTSC/PAL
White Balance	Auto
